The machine is widely used for the mixing of powder materials in the industry of pharmacy, chemical industry, food and so on; as well as for quick and even mixing of various materials in different granule size and gravity.
Products Details
TECHNICAL PARAMETERS:
| Type | SYH-10 | SYH-50 | SYH-100 | SYH-200 | SYH-400 | SYH-600 | SYH-800 | SYH-1000 |
| Barrel volume （L） | 10 | 50 | 100 | 200 | 400 | 600 | 800 | 1000 |
| Max. loading volume (L) | 8 | 40 | 80 | 160 | 320 | 480 | 640 | 800 |
| Max. loading weight(kg) | 5 | 25 | 50 | 100 | 200 | 300 | 400 | 500 |
| Spindle speed（r/min） | 0-30 | |||||||
| Power（KW） | 0.37 | 1.1 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 7.5 |
| Overall size（L*W*H） (mm) | 600*1000*700 | 1000 *1400 *1100 | 1200*1700*1200 | 1400 *1800 *1500 | 1800 *2100 *1800 | 1900 *2100 *2100 | 2200 *2400 *2250 | 2250*2600*2400 |
| Weight (kg) | 150 | 300 | 500 | 800 | 1200 | 1500 | 2000 | 2500 |
